5L oxygen concentrator light weight 14.5kgs optional with nebulizer and purity alarm

5L oxygen concentrator light weight 14.5kgs optional with nebulizer and purity alarm

Oxygen concentrator

Product Detail:

♦Superior oxygen Atomizing technology

♦Advanced PSA technology

♦France Imported molecular sieve bed

♦Power-off alarming system

♦Timing system and time setting

♦Compact design and light weight 14.5kg only

♦Environmental protective, without harmful during using

Functions:

♦Power off alarm, Overload protection, High/Low pressure alarm, Temperature alarm, Error code indication, Nebulizer, Oxygen purity alarm

Specification:

♦ Model: KSN-5 Elite

♦ Oxygen Purity: 93±3%

♦ Flow Range: 1-5L

♦ Input Voltage: 220V/50HZ

♦ Output Pressure: 30-70kPa

♦ Noise:45dB

♦ Power: 350W

♦ Weight: 14.5kg

♦ Size: 350mm×340mm×475mm

The performance instruction：

♦Classical of electrical safety: II Equipment, BF type application

♦Running model: continuous operation.

♦Outlet pressure：0.04 MPa～0.08MPa

♦Pressure range of the atomization outlet is 60kPa~250kPa. Safety valve ♦pressure range：15 kPa～40 kPa

♦Overloading protector specification：250V AC, 3A；

How to use the function of nebulizer

♦Take out the accompanied nebulizer, pour into proper atomized liquid by doctor’s advice, fix the water laps and tighten the cover in the clockwise.

♦Unscrew the atomization cap and insert the atomization tube. Connect the other head of the atomization tube with the connecting nozzle on the nebulizer bottom.

♦Turn on the oxygen concentrator and then put the mouthpiece into mouth and then the inhalation therapy starts.

♦The pressure range of atomizing oxygen concentrator is 60kPa~ 250kPa.

♦The atomization rate of the nebulizer on the oxygen concentrator≧0.2mL/ min.
